PV-12150E (150W 220-240V AC-DC 12V)

PV-12150E Type: Constant Voltage High Efficiency LED Driver Power: 150W IP rate: IP67 Input voltage:220-240V AC Output voltage: 12V DC Output current: 12.5A Efficiency: 93% Size:183*51*32mm(L*W*H)

Product Features

Constant voltage design (CV Mode) Small size, high efficiency With short circuit protection With output overload protection 100% full load aging With class 1 protection Withstand voltage:I/P-0/P:3.75KVACI/P-FG:2KVAC O/P-FG: 1.5KVAC Operatingtemperature:-40°C~+60°C Using environment: suitable for dry and humid areas Protection grade:lP67 Safety standards:lEC61347-2-13 2014+A1 IEC 61347-1 2015+A1 3-year warranty

Category:

IP67 High Effciency

Keywords:

PT Power LED Driver

Constant Voltage High Efficiency LED Driver

IP67 Waterproof led driver

Product Inquiry

PV-12-24150E Datasheet -.pdf

Product Details

Technical Parameters

Model	Power	Input Voltage Range	Output Voltage	Output Current	Efficiency	Weight	Dimensions
PV-12100E	100W	220-240VAC	12VDC	0-8.33A	>=92%	260g	17736.522mm
PV-24100E	100W	220-240VAC	24VDC	0-4.17A	>=93%	260g	17736.522mm
PV-12150E	150W	220-240VAC	12VDC	0-12.5A	>=93%	550g	1835132mm
PV-24150E	150W	220-240VAC	24VDC	0-6.25A	>=94%	550g	1835132mm
PV-12200E	200W	220-240VAC	12VDC	0-16.7A	>=93%	560g	1936432mm
PV-24200E	200W	220-240VAC	24VDC	0-8.33A	>=94%	560g	1936432mm
PV-12300E	300W	220-240VAC	12VDC	0-25.0A	>=92%	800g	2487032mm
PV-24300E	300W	220-240VAC	24VDC	0-12.5A	>=93%	800g	2487032mm
PV-12400E	400W	220-240VAC	12VDC	0-33.3A	>=92%	1100g	2637032mm
PV-24400E	400W	220-240VAC	24VDC	0-16.7A	>=93%	1100g	2637032mm

The IP67 Waterproof LED Driver is a robust and versatile power supply designed to deliver consistent performance in challenging conditions. With its IP67-rated waterproof and dustproof enclosure, this driver is perfect for outdoor and industrial applications, including landscape lighting, signage, and underwater installations. Built to withstand rain, humidity, and extreme temperatures, it ensures reliable operation in even the harshest environments.

This high-efficiency LED driver provides stable and flicker-free power, ensuring optimal performance for your LED lighting systems. It features advanced protection mechanisms, including over-voltage, over-current, and short-circuit safeguards, to extend the lifespan of your LEDs and prevent damage. The compact and durable design makes it easy to install in tight or exposed spaces, while its energy-efficient operation helps reduce power consumption and lower costs.

Ideal for architects, contractors, and lighting professionals, the IP67 Waterproof LED Driver combines durability, safety, and performance. Whether you're illuminating a garden, enhancing building facades, or powering industrial lighting, this driver is the perfect choice for demanding applications. Upgrade to the IP67 Waterproof LED Driver and experience unmatched reliability and efficiency in any environment. Light up your outdoor and harsh-condition spaces with confidence!
