Zhuhai Ptpower Electronic Technology Co., Ltd.

PV-12060P (60W 170-264V AC-DC 12V)

PV-12060P Type: Constant Voltage EMC LED Driver Power: 60W IP Rate: IP66 Input voltage: 170-264V AC Output voltage: 12V DC Output current: 5A Efficiency: 85% Power factor: PF 0.95 Size: 162*43*32mm(L*W*H)

Product Features

Constant voltage design (CV Mode) With short circuit protection With output overload protection, over temperature protection (PV-100W,PV-150W) 100% full load aging With class 1 protection Withstand voltage: I/P-0/P: 3KVAC Operatingtemperature:-40°C~+50°C Protection grade:lP66 EMC standard: EN55032,EN61000-3-2,EN61000-3-3,EN55024 Safety standards:EN61347-1,EN61347-2-13 3-year warranty

Category:

IP66 Regular Plastic Shell

Keywords:

PT Power LED Driver

Constant Voltage EMC LED Driver

IP66 Waterproof Plastic Case LED Driver

Product Inquiry

PV-12-24060P(EMC) Datasheet.pdf

Product Details

Technical Parameters

Model	Power	Input Voltage Range	Output Voltage	Output Current	Efficiency	Weight	Power Factor	Dimensions
PV-12030P	30W	170-264VAC	12VDC	0-2.5A	>=83%	240g	>=0.95	15139.530mm
PV-24030P	30W	170-264VAC	24VDC	0-1.25A	>=84%	240g	>=0.95	15139.530mm
PV-12060P	60W	170-264VAC	12VDC	0-5.0A	>=85%	360g	>=0.95	1624332mm
PV-24060P	60W	170-264VAC	24VDC	0-2.5A	>=86%	360g	>=0.95	1624332mm
PV-12100P	100W	170-264VAC	12VDC	0-8.33A	>=85%	690g	>=0.95	1906238mm
PV-24100P	100W	170-264VAC	24VDC	0-4.17A	>=87%	690g	>=0.95	1906238mm
PV-12150P	150W	170-264VAC	12VDC	0-12.5A	>=88%	710g	>=0.95	1906238mm
PV-24150P	150W	170-264VAC	24VDC	0-6.25A	>=89%	710g	>=0.95	1906238mm
