Zhuhai Ptpower Electronic Technology Co., Ltd.

PV-12100S (100W 170-264V AC-DC 12V)

PV-12100S Type: Constant Voltage EMC LED Driver Power: 100W IP Rate: IP67 Input voltage: 170-264V AC Output voltage: 12V DC Output current: 8.33A Efficiency: 86% Size:230*42*30mm(L*W*H)

Product Features

Constant voltage design (CV Mode) Ultra-thin size design With short circuit protection With output overload protection 100% full load aging With class 1 protection Withstand voltage:I/P-O/P:3.75KVACI/P-FG: 2KVAC O/P-FG: 1.5KVAC Operating temperature:-40°C~+70°C Using environment: suitable for dry and humid areas Protection grade:lP67 EMC standard: EN55032,EN61000-3-2,EN61000-3-3,EN55024 Safety standards:EN61347-1,EN61347-2-13 3-year warranty

Category:

IP67 Regular Metal Shell

Keywords:

PT Power LED Driver

Constant Voltage EMC LED Driver

IP67 Waterproof led driver

Product Inquiry

PV-12-24100S (EMC) Datasheet.pdf

Product Details

Technical Parameters

Model	Power	Input Voltage Range	Output Voltage	Output Current	Efficiency	Weight	Dimensions
PV-12030	30W	170-264VAC	12VDC	0-2.5A	>=83%	240g	2203020mm
PV-24030	30W	170-264VAC	24VDC	0-1.25A	>=85%	240g	2203020mm
PV-12060S	60W	170-264VAC	12VDC	0-5.0A	>=85%	380g	1804230mm
PV-24060S	60W	170-264VAC	24VDC	0-2.5A	>=86%	380g	1804230mm
PV-12100S	100W	170-264VAC	12VDC	0-8.33A	>=86%	500g	2304230mm
PV-24100S	100W	170-264VAC	24VDC	0-4.17A	>=87%	500g	2304230mm
PV-12150S	150W	170-264VAC	12VDC	0-12.5A	>=88%	615g	2804230mm
PV-24150S	150W	170-264VAC	24VDC	0-6.25A	>=89%	615g	2804230mm
PV-12200S	200W	170-264VAC	12VDC	0-12.5A	>=88%	1000g	2248031mm
PV-24200S	200W	170-264VAC	24VDC	0-6.25A	>=89%	1000g	2248031mm
PV-12300S	300W	170-264VAC	12VDC	0-12.5A	>=88%	1300g	2748031mm
PV-24300S	300W	170-264VAC	24VDC	0-6.25A	>=89%	1300g	2748031mm
